BENO Medium Sizer is the equipment often chosen for the secondary crushing stage. Due to its extrusion, cutting and crushing principle, the material yield reaches 60%. BENO Medium Sizer is different from other crushing equipment in that it operates at a low speed, which not only reduces the scrap rate, but also greatly enhances the safety of the operation.
Coal Industry：BENO Medium sizer can be used in the coal industry. Since coal is a material with high moisture content, it is not easy to be broken by traditional crushers. However, BENO Medium Sizer can effectively solve this problem because it adopts the principle of low-speed and high-pressure extrusion crushing, which can effectively crush coal while reducing moisture content.
Chemical Industry: BENO Medium Sizer can be used in the chemical industry. In the chemical industry, there are many materials that need to be crushed, such as ammonium nitrate, urea, etc. BENO Medium sizer can not only crush these materials, but also has the advantages of low dust, low noise, no pollution, etc., and meets environmental protection requirements.
Cement Industry: BENO Medium Sizer can be used in the cement industry. In the cement industry, materials such as limestone, clay and gypsum need to be crushed and refined. BENO Medium Sizer can not only crush these materials, but also has the advantages of uniform particle size, low energy consumption and high efficiency, which can greatly improve the quality of cement products.
Metallurgical Industry: BENO Medium Sizer can be used in the metallurgical industry. In the metallurgical industry, there are many materials that need to be crushed, such as iron ore, copper ore, gold ore, etc. Medium sizer can effectively crush these materials, which not only saves energy, but also improves the efficiency of ore processing.
Specification | Roller diameter（mm） | Roller length （mm） | Maximum feed side length （mm） | Size of discharge （mm） | Production capacity （t/h） | Motor power （kw） | Soft link weight（t） | Direct link weight（t） |
XCMD500 | 500 | 1000 | ≤100 | ≤30-60 | 50-120 | 37*2 | 9.5 | 8.2 |
1500 | 100-180 | 45*2 | 11.8 | 10.5 | ||||
2000 | 150-220 | 90*2 | 14.5 | 12.8 | ||||
2500 | 200-300 | 110*2 | 18 | 16.3 | ||||
XCMD650 | 650 | 1000 | ≤120 | ≤30-60 | 50-130 | 45*2 | 12.3 | 10.5 |
1500 | 100-255 | 55*2 | 18.5 | 16 | ||||
2000 | 200-350 | 75*2 | 23 | 21 | ||||
2500 | 350-450 | 90*2 | 28 | 25 | ||||
XCMD750 | 750 | 1000 | ≤140 | ≤40-70 | 150-250 | 55*2 | 23 | 21 |
1500 | 200-350 | 75*2 | 26.5 | 24.5 | ||||
2000 | 250-450 | 90*2 | 30 | 27.2 | ||||
2500 | 350-550 | 110*2 | 33.8 | 30.8 | ||||
XCMD850 | 850 | 1000 | ≤160 | ≤40-70 | 150-300 | 75*2 | 26 | 23.5 |
1500 | 200-400 | 90*2 | 31.5 | 28.5 | ||||
2000 | 300-500 | 110*2 | 36 | 33 | ||||
2500 | 350-650 | 132*2 | 39 | 36 | ||||
XCMD1000 | 1000 | 1000 | ≤220 | ≤40-80 | 250-450 | 90*2 | 46.8 | 41 |
1500 | 350-550 | 110*2 | 52 | 46.2 | ||||
2000 | 500-700 | 132*2 | 58 | 52.5 | ||||
2500 | 650-800 | 160*2 | 65 | 60 | ||||
XCMD1200 | 1200 | 1500 | ≤250 | ≤40-90 | 650-900 | 160*2 | 81 | 73 |
2000 | 750-1100 | 185*2 | 93 | 85 | ||||
2500 | 900-1500 | 220*2 | 106 | 98 | ||||
XCMD1500 | 1500 | 1500 | ≤300 | ≤40-90 | 1000-1800 | 220*2 | 102 | 94 |
2000 | 1500-2200 | 285*2 | 116 | 108 | ||||
2500 | 2000-3000 | 355*2 | 132.5 | 125 | ||||
3500 | 3000-5000 | 420*2 | 185 | 177 |
BENO Medium sizer can crush a variety of materials, mainly soft rock, such as coal, coke, limestone, basalt, etc. It is often used in industry to crush coal and coke.
When selecting a medium sizer, you should consider the material to be crushed, the feed particle size, the required production capacity, and the discharge particle size. Of course, we also provide you with adapted solutions.
You can tell us your name, company information and contact information through the inquiry button or email. We will contact you as soon as possible.
